Stainless Steel Wall-Mounted Instrument Box with IP55 Protection

Quantity:
SKU: 9595162531
Model: customizable

{{ variable.name }}

{{ value.name }}
Product Details

Stainless Steel Wall-Mounted Instrument Box (304 Grade)

This wall-mounted instrument box is fabricated from 304 stainless steel with a brushed finish, providing reliable corrosion resistance for atmospheric and fresh water environments. It features IP55 protection, a 2.0mm thick body, and a customizable design to accommodate instruments, switches, and terminals. The box is suitable for chemical, petroleum, food & pharma, and municipal applications.

Key Selling Points

  • 304 Stainless Steel Construction: Withstands atmospheric and fresh water corrosion, ensuring long service life in outdoor and industrial environments.
  • IP55 Protection: Dustproof and water-resistant, safeguarding internal instruments from harsh conditions.
  • Customizable Cutouts: Instrument windows, button holes, and sensor ports can be tailored to your exact requirements.
  • Wall-Mounted Design: 4 pre-drilled mounting holes on the back allow for easy installation onto walls or equipment.
  • Secure Door with EPDM Seal: Single or double door options with stainless steel plane locks and rubber sealing to prevent water ingress.

Technical Specifications

Material304 Stainless Steel
Thickness2.0 mm
Surface TreatmentBrushed Finish
Protection LevelIP55
InstallationWall-mounted with 4 pre-drilled holes
Door StructureSingle/Double door
SealingEPDM rubber seal
Internal ConfigurationMounting plate, DIN rail, grounding bar
Cable EntryKnockout holes with waterproof glands

Models and Options

Custom sizes available to fit specific instrument dimensions and cutout layouts. Options include different door types, handle locks, and mounting accessories.

Materials and Structure

304 stainless steel with brushed finish. Door is equipped with EPDM seal and grounding jumper. Internal mounting plate and DIN rail are included for easy equipment mounting.

Applications

Widely used in chemical, petroleum, mining, food & pharmaceutical, municipal environmental protection, and power industries. Ideal for housing pressure gauges, transmitters, terminal blocks, and small PLC modules.

Customization

Cutouts for instruments, buttons, and sensors; cable entry holes; doors with locks; and surface finishes can be customized per project. Contact us with your specifications.

FAQ

What is the minimum order quantity?

MOQ is 1 unit.

Can you provide CE certification?

Yes, our control cabinets comply with EN 60529 and have SGS CE verification.

What is the typical delivery time?

Please contact us for current lead times.

Do you offer custom sizes?

Yes, sizes are customizable based on instrument dimensions and cutout layout.

What payment methods do you accept?

We accept TT, PayPal, LC, Visa.

Inquiry Information

Contact Eric: Sales@innometalfab.com | +86 186-2435-1618 | WhatsApp: +86 186-2435-1618

Product Images

Wall-mounted instrument box with stainless steel surface Wall-mounted instrument box front view with door Wall-mounted instrument box interior with mounting plate
