Stainless Steel Electrical Control Cabinet - 304 Wall Mounted
This IP54 304 stainless steel wall-mounted electrical control cabinet is designed for corrosive and hygienic environments. The main body is fabricated from 304 stainless steel with a plate thickness of at least 2.0mm, providing robust protection for your electrical components. It features an EPDM sealing strip on the door frame to ensure dust and water resistance. Ideal for food & pharmaceutical, chemical, water treatment, and marine applications. CE certified and manufactured under ISO9001 quality management system.
Product Summary
This wall-mounted control cabinet is a reliable housing solution for industrial automation, power distribution, and control systems. With an IP54 protection rating, it shields internal components from dust and water splashes. The 304 stainless steel construction ensures excellent corrosion resistance, making it suitable for coastal and chemical processing areas. It can be equipped with DIN rails, mounting plates, grounding bars, and cable ducts to accommodate PLCs, frequency converters, circuit breakers, and terminals.
Key Features
- Durable 304 Stainless Steel: Main body made of 304 stainless steel with thickness ≥2.0mm, offering long-lasting performance in corrosive environments.
- IP54 Protection: Sealed with EPDM gasket to resist dust and water ingress, complying with EN 60529 standard.
- Flexible Internal Configuration: Accepts DIN rails, mounting plates, cable ducts, grounding bars, and various electrical components.
- Certified Quality: CE and ISO9001 certified, ensuring compliance with international standards.
- Easy Installation: Wall-mounted design with knockouts for cable entry, simplifying setup.
- Customizable Options: Optional accessories like observation window, lighting, and padlock for enhanced functionality.
Technical Specifications
| Parameter | Value |
|---|
| Material | 304 Stainless Steel |
| Plate Thickness | ≥2.0mm |
| Protection Grade | IP54 / IP55 |
| Installation | Wall-mounted |
| Ambient Temperature | -20°C to +60°C |
| Relative Humidity | ≤95% (non-condensing) |
| Altitude | ≤4000m |
| Rated Voltage | AC 220V/380V, DC 24V/48V |
| Standards | EN 60529, GB/T 13384 |
Models and Options
This model is customizable in size, internal layout, door configuration (single or double), and accessories. Optional features include observation window, lighting lamp, keyboard drawer, casters, and adjustable feet. Heat dissipation solutions such as axial fans, heat exchangers, or industrial air conditioners can be added based on heat generation.
Materials and Structure
Constructed from 304 stainless steel, the cabinet features a robust welded frame with a smooth, brushed finish. The door is fitted with a flat lock or handle lock and an EPDM sealing strip to maintain IP protection. Internal components are mounted on galvanized steel plates or DIN rails, ensuring stable installation. Cable entry is via knockouts at the bottom or back, equipped with stainless steel cable glands for waterproofing.
Applications
Suitable for a wide range of industries including food & pharmaceutical, chemical, water treatment, marine, heavy industry, mining, new energy, and electronics. It provides reliable enclosure for PLCs, VFDs, circuit breakers, and other control equipment in corrosive or washdown environments.
Customization
We offer custom fabrication services to meet specific requirements: custom dimensions, cutouts for instruments, cable entry configurations, and special finishes. OEM and ODM projects are welcome. Our engineering team can assist in designing a cabinet that fits your exact application.
FAQ
What is the minimum order quantity?
Our MOQ is 1 unit.
What payment methods do you accept?
We accept TT, PayPal, LC, and Visa.
How is the cabinet shipped?
We support FOB, CIF, EXW, DAP, CFR, and DDP delivery methods.
Can I get a sample before bulk order?
Yes, we can provide samples for verification.
Do you provide custom sizes?
Yes, custom dimensions are available upon request.
What is the warranty period?
We offer a standard warranty, please contact us for details.
How do I ensure proper grounding?
The cabinet must be grounded with resistance ≤4Ω, and we provide grounding bars as an option.
