Customizable Sloped PLC Control Console
This customizable sloped PLC control console is designed for industrial automation and command center applications. It features a cold-rolled steel (SPCC) construction with 3.0mm thickness, providing a robust and durable housing for your control equipment. The phosphating derusting and electrostatic powder coating finish in RAL7035 light gray (or customizable two-tone) offers scratch resistance and anti-fingerprint properties. With IP54 protection, it is suitable for dust and splash-prone environments such as command centers and equipment rooms.
Key Features
- IP54 Protection: Dustproof and splash-proof, ideal for command center and equipment room environments.
- Ergonomic Sloped Design: Sloped upper section designed for multi-screen viewing, reducing operator fatigue.
- Integrated Cable Management: Separate strong/weak current cable ducts and pre-drilled holes ensure organized and safe cable routing.
- Customizable Configuration: Supports curved or corner splicing to form circular or linear dispatch consoles, adaptable to your space and equipment needs.
- Flame Retardant Materials: Countertop and cabinet materials comply with V-0 flame retardant standard for enhanced safety.
Technical Specifications
| Material | Cold-rolled steel (SPCC) |
|---|
| Thickness | 3.0mm |
|---|
| Surface Treatment | Phosphating derusting + electrostatic powder coating |
|---|
| Color | RAL7035 light gray/white, customizable two-tone |
|---|
| Protection Level | IP54 |
|---|
| Installation | Floor-standing with adjustable feet |
|---|
| Ambient Temperature | 0°C to +45°C |
|---|
| Relative Humidity | ≤85% (no condensation) |
|---|
| Altitude | ≤2000m |
|---|
| Vibration Resistance | Compliant with GB/T 13384 |
|---|
| Flame Retardancy | V-0 standard |
|---|
Models and Options
Customizable radian, size, and splicing mode based on display quantity, workstation count, and space layout. Options include door configurations (single/double/multi-door), lock types, and ventilation features.
Materials and Structure
Cold-rolled steel (SPCC) with 3.0mm thickness ensures structural integrity. Upper sloped section: ergonomic operation area; lower section: multi-door equipment compartment with removable back panel for maintenance. The structure supports seamless curved or corner splicing for custom layouts.
Applications
Smart city, traffic command, power dispatch, security monitoring, emergency command, rail transit, and smart factory applications.
Customization
Customize size, color, cutouts for displays, buttons, and instruments. Optional axial fans for enhanced heat dissipation. Panel functions can be integrated per your requirements.
FAQ
What is the minimum order quantity (MOQ)?
MOQ is 1 unit.
What are the accepted payment methods?
TT, PayPal, LC, Visa.
What is the lead time for custom orders?
Lead time depends on customization complexity; please contact us for specifics.
Does the console meet any safety standards?
Yes, materials comply with V-0 flame retardant standard and the console meets GB/T 13384 for vibration resistance.
Can the console be installed outdoors?
No, it is designed for indoor environments with temperature control.
Can we choose a different color?
Yes, color is customizable, including two-tone options.
Is the console suitable for 24/7 operation?
Yes, it is a passive structure designed for continuous operation of internal equipment.
What is the warranty period?
Please contact our sales team for warranty details.
Inquiry Information
For pricing and additional information, contact our sales team at Sales@innometalfab.com or +86 186-2435-1618.
Image Filenames and Alt Suggestions
- File: plc-control-console-sloped-RAL7035.png - Alt: PLC control console with sloped operation area and RAL7035 finish
- File: plc-control-console-equipment-compartment.png - Alt: PLC control console lower equipment compartment with doors
- File: plc-control-console-front-view.png - Alt: PLC control console front view with adjustable feet
