Sloped Industrial Control Console
Customized for Your Operation Interface
Product Summary
The Sloped Industrial Control Console is a floor-standing enclosure designed for industrial automation, equipment manufacturing, and testing environments. Its ergonomic sloped panel (15°-30°) optimizes operator line-of-sight and reach. Constructed from 2.0mm cold-rolled steel with IP54 protection, it ensures durability and resistance to dust and splashes. Built-in cable management keeps the workspace tidy, and the customizable cutouts accommodate instruments, buttons, and displays. Suitable for workshops, test rooms, and control rooms.
Key Features
IP54 Protection
Dustproof and splash-proof, suitable for demanding industrial environments.
Ergonomic Slope
15°-30° adjustable slope reduces operator fatigue.
2.0mm Steel Body
Cold-rolled steel provides robust structural integrity.
V-0 Flame Retardant
Materials comply with V-0 standard for electrical safety.
Custom Cutouts
Panel can be precisely machined for instruments, switches, displays.
Cable Management
Integrated cable ducts and routing space keep cables organized.
Technical Specifications
| Parameter | Value |
|---|
| Thickness | 2.0mm |
| Surface Treatment | Phosphating derusting + electrostatic powder coating |
| Color | RAL7035 (light gray/white) |
| Protection Level | IP54 |
| Installation | Floor-standing, adjustable feet, optional casters |
| Structure | Upper sloped area (15°-30°), lower equipment compartment |
| Door/Drawer | Single/double doors/drawers with locks |
| Cable Management | Built-in cable ducts, bottom/back cable holes |
| Size | Customized per requirements |
| Ambient Temp | 0℃ ~ +50℃ |
| Flame Retardancy | V-0 compliant |
| Grounding | Resistance ≤4Ω |
| Heat Dissipation | Side/bottom vents, optional axial fans |
Models and Options
Customizable model: Structure, size, and panel layout can be tailored to specific equipment and operational needs. Options include drawers, doors, keyboard tray, mouse tray, display bracket, cable ducts, lighting, locks, and PDU power sockets.
Materials and Structure
Made from cold-rolled steel with a minimum thickness of 2.0mm. The cabinet features a sloped top section for ergonomic access, and a lower section with compartments for mounting industrial PCs, power supplies, and test instruments. All materials meet V-0 flame retardancy standards.
Applications
Designed for industrial automation, equipment manufacturing, electronic testing, power debugging, research laboratories, and military testing environments. It is ideal for use in workshops, test rooms, and control rooms that require a clean, non-corrosive indoor atmosphere.
Customization
Fully customizable: panel cutouts (instrument windows, button holes, indicator holes, display mounting holes, test interfaces), color options (custom olive green/light olive by project specification), surface finish, internal layout, and optional accessories. Grounding and safety requirements are integrated into the design.
FAQ
What is the MOQ?
MOQ is 1 unit, allowing you to order for testing or small projects.
What payment methods do you accept?
We accept TT, PayPal, LC, and Visa.
What are the available delivery terms?
We offer FOB, CIF, EXW, DAP, CFR, and DDP.
Can I get a customized panel cutout?
Yes, we customize the sloped panel cutouts to match your specific instrument dimensions and layout.
What is the protection level?
The console provides IP54 protection, suitable for workshop and test room environments.
Does the console comply with safety certifications?
Our manufacturing process is ISO 9001:2015 certified, and materials meet V-0 flame retardancy.
Can the console be moved easily?
Yes, it comes with adjustable feet for leveling, and optional casters for mobility.
