316 Stainless Steel Outdoor Electrical Control Cabinet

This outdoor enclosure is manufactured from 316 stainless steel, offering superior resistance to strong acids, alkalis, salt spray, and seawater corrosion. Designed for extreme environments, it can operate in temperatures from -40°C to +80°C. With an IP66 protection rating, it is dust-tight and protected against powerful water jets, making it ideal for coastal, offshore, and chemical processing facilities. The cabinet is wall-mounted and includes features like a stainless steel flat lock, EPDM sealing strip, and optional observation window.

Product Summary

This high-performance 316 stainless steel cabinet is engineered for demanding outdoor conditions, including exposure to UV, salt, and chemicals. It provides a secure and durable housing for electrical and automation components, ensuring reliable operation in remote or harsh sites. The cabinet supports a wide range of internal configurations, including DIN rails, mounting plates, and cable ducts. It is ideal for new energy, petrochemical, marine, and water treatment applications.

Key Features

• Superior Corrosion Resistance: 316 stainless steel withstands salt spray, acids, and alkalis, ensuring long service life in coastal or chemical environments.
• IP66 Protection: Dust-tight and protected against powerful water jets, meeting EN 60529 requirements.
• Wide Temperature Range: Operates from -40°C to +80°C, suitable for extreme climates.
• Vibration Resistant: Complies with GB/T 13384, ideal for mining, ports, and heavy industries.
• Flexible Design: Customizable with observation window, lighting, and various mounting options.
• CE Certified: Complies with EN 60529 and EU Low Voltage Directive.

Technical Specifications

Models and Options

Available in various sizes to accommodate different component layouts. Options include double doors, observation windows, cable glands, heaters, and cooling fans. Custom cutouts for instruments and buttons can be provided.

Materials and Structure

Fabricated from 316 stainless steel, the cabinet features a robust welded construction with a smooth, easy-to-clean surface. The door includes a heavy-duty lock and EPDM gasket for a secure seal. Internal mounting plates are made of galvanized steel, and cable entry points are equipped with stainless steel waterproof connectors.

Applications

Perfect for offshore platforms, coastal power plants, chemical plants, water treatment facilities, and marine vessels. Also suitable for outdoor telecom, renewable energy (PV, wind), and infrastructure projects.

Customization

We offer complete customization services: size, door configuration, internal layout, and accessory options. Our engineers can work with you to design a cabinet that meets your exact requirements and environmental conditions.

FAQ

Can this cabinet be used in marine environments?

Yes, the 316 stainless steel construction provides excellent resistance to saltwater corrosion, making it suitable for ships and offshore platforms.

What is the MOQ?

MOQ is 1 unit, suitable for trial orders.

What payment terms are available?

We accept TT, PayPal, LC, and Visa.

How is the cabinet packaged for shipment?

We use sturdy export-grade plywood cases with foam padding to protect the cabinet during transit.

Can I request a custom size?

Absolutely, we specialize in custom metal enclosures; please provide your specifications.

Do you provide installation guidance?

Yes, we offer detailed installation manuals and technical support.

What standards does this cabinet meet?

It meets EN 60529 for IP ratings and GB/T 13384 for vibration resistance.

Inquiry Information

For pricing and further information, contact:
Email: Sales@innometalfab.com | Phone/WhatsApp: +86 186-2435-1618
Address: Yangquanzi Village, Gezhenpu Town, Ganjingzi District, Dalian City, Liaoning Province, China
